Electrical Characteristics

Number of Phase  2
Step Angle 1.8°
Rated Voltage 4.2V DC
Rated Current 2.0A
Holding Torque  800mN.m Min (2 Phases)
Phase Resistance 2.1 Ω ± 10% (20°C)
Phase Inductance 5.0mH± 20% (1kHz 1V rms)
Motor Inertia 180g. cm^2
Motor Weight 500g Ref.
Insulation Resistance 100MΩ Min. (DC 500V)
Insulation Class B (130° C)
