Electrical Characteristics

Number of Phase  2
Step Angle 1.8°
Rated Voltage 3.84V DC
Rated Current 0.8A
Holding Torque  65mN.m Min (2 Phases)
Phase Resistance 4.8 Ω ± 10% (20°C)
Phase Inductance 2.8mH± 20% (1kHz 1V rms)
Motor Inertia 5.5g. cm^2
Motor Weight 80g Ref.
Insulation Resistance 100MΩ Min. (DC 500V)
Insulation Class B (130° C)
